| Senzor de imagine |
1/2.8" Progressive Scan CMOS |
| Iluminare minima |
Culoare: 0.005 Lux @ (F1.6, AGC ON), 0 Lux cu IR pornit |
| Viteza obturatorului |
1/3 s pana la 1/100,000 s |
| Obturator lent |
Da |
| Wide Dynamic Range |
120 dB |
| Zi si Noapte |
ICR Cut |
| Ajustare unghi |
Pan: 0° pana la 360°, Tilt: 0° pana la 75°, rotate: 0° pana la 360° |
| Tip lentila si FOV |
2.8 pana la 12 mm, Unghi orizontal 106.6° pana la 31.7°, Unghi vertical 54.7° pana la 17.7°, Unghi diagonal 130.3° pana la 36.4° |
| Apertura |
F1.6 |
| Montura lentila |
Ø 14 |
| DORI |
2.8 pana la 12 mm: D: 44.1 m pana la 137.9 m, O: 17.5 m pana la 54.7 m, R: 8.8 m pana la 27.5 m, I: 4.4 m pana la 13.8 m |
| Distanta IR |
Pana la 40 m |
| Lungime de unda |
850 nm |
| Rezolutie maxima |
1920 × 1080 |
| Flux principal |
50 Hz: 25 fps (1920 × 1080, 1280 × 720) / 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Sub-flux |
50 Hz: 25 fps (640 × 480, 640 × 360) / 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Al treilea flux |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) / 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Compresie video |
Flux principal: H.265/H.264/H.264+/H.265+ / Sub-flux: H.265/H.264/MJPEG / Al treilea flux: H.265/H.264 |
| Rata de biti video |
32 Kbps pana la 8 Mbps |
| Tip H.264 |
Baseline Profile/Main Profile/High Profile |
| Tip H.265 |
Main Profile |
| H.264+ |
Suporta flux principal |
| H.265+ |
Suporta flux principal |
| Control rata de biti |
CBR/VBR |
| Scalable Video Coding |
Da |
| Region of Interest (ROI) |
1 regiune fixa pentru flux principal si sub-flux |
| Filtrare zgomot ambiental |
Da |
| Rata de esantionare audio |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Compresie audio |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Rata de biti audio |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16-64 Kbps (AAC-LC)/32-192 Kbps (MP2L2)/8-320 Kbps (MP3) |
| Vizualizare live |
Pana la 6 canale |
| API |
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK |
| Protocol |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets |
| Utilizatori/Gazda |
Pana la 32 utilizatori. 3 nivele de utilizatori: administrator, operator si utilizator |
| Protectie parola |
Protectie prin parola, parola complicata, criptare HTTPS, filtru adrese IP, jurnal audit de securitate, autentificare de baza si digest pentru HTTP/HTTPS, TLS 1.1/1.2, WSSE si autentificare digest pentru Open Network Video Interface |
| Stocare retea |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Browser web |
Plug-in necesar pentru vizualizare live: IE 10, IE 11 / Fara plug-in pentru vizualizare live: Chrome 57.0+, Firefox 52.0+ / Serviciu local: Chrome 57.0+, Firefox 52.0+ |
| Zi/Noapte |
Zi, Noapte, Auto, Programat |
| Imbunatatirea imaginii |
BLC, HLC, 3D DNR |
| Comutare parametri imagine |
Da |
| Setari imagine |
Rotire, oglinda, masti de confidentialitate, saturatie, luminozitate, contrast, claritate, ajustare gain, balans de alb ajustabil prin software-ul client sau browser web |
| Audio |
1 intrare (line in), bloc terminal cu doua nuclee, amplitudine maxima intrare: 3.3 Vpp, impedanta intrare: 4.7 KΩ, tip interfata: neechilibrata / 1 iesire (line out), bloc terminal cu doua nuclee, amplitudine maxima iesire: 3.3 Vpp, impedanta iesire: 100 Ω, tip interfata: neechilibrata |
| Alarma |
1 intrare, 1 iesire (max. 12 VDC, 30 mA) |
| Stocare pe placa |
microSD incorporat, pana la 512 GB |
| Reset hardware |
Da |
| Interfata de comunicatie |
1 RJ45 10M/100M port Ethernet auto-adaptiv |
| Eveniment de baza |
Detectie miscare (clasificare tinte umane si vehicule), alarma de manipulare video, exceptii |
| Detectie fata |
Da |
| Protectie perimetru |
Detectie traversare linie, detectie intruziune, suporta clasificare tinte umane si vehicule |
| Metoda de legare |
Incarcare pe FTP/card de memorie/NAS, notificare centru de supraveghere, declansare inregistrare, declansare captura, Email |
| Functii generale |
Anti-flicker, heartbeat, resetare parola prin email, contor pixeli |
| Resetare software |
Da |
| Conditii de stocare |
-30 °C pana la 60 °C (-22 °F pana la 140 °F). Umiditate 95% sau mai putin (fara condens) |
| Conditii de operare |
-30 °C pana la 60 °C (-22 °F pana la 140 °F). Umiditate 95% sau mai putin (fara condens) |
| Alimentare |
12 VDC ± 25%, protectie polaritate inversa, PoE: 802.3af, Clasa 3 |
| Consum si curent |
12 VDC, 0.92 A, max. 11 W, PoE: (802.3af, 36 V pana la 57 V), 0.35 A pana la 0.22 A, max. 12.5 W |
| Interfata de alimentare |
Ø 5.5 mm coaxial power plug |
| Material |
Corp din aliaj de aluminiu |
| Dimensiune camera |
Ø 138.3 × 126 mm (Ø 5.4" × 5.0") |
| Dimensiune pachet |
170 × 170 × 150 mm (6.7" × 6.7" × 5.9") |
| Greutate camera |
Aproximativ 830 g (1.8 lb.) |
| Greutate cu pachet |
Aproximativ 1115 g (2.5 lb.) |
