| Senzor de imagine |
1/2.9" CMOS |
| Rezolutie maxima |
2688 (H) × 1520 (V) |
| ROM |
128 MB |
| RAM |
128 MB |
| Sistem de scanare |
Progresiv |
| Viteza obturatorului electronic |
Auto/Manual 1/3 s–1/100,000 s |
| Iluminare minima |
0.006 [email protected] (Color, 30 IRE); 0.0006 [email protected] (B/W, 30 IRE); 0 lux (Iluminator pornit) |
| Raport S/N |
＞56 dB |
| Distanta de iluminare |
Pana la 30 m (98.43 ft) (IR)
Pana la 30 m (98.43 ft) (Lumina calda)
|
| Control pornire/oprire iluminator |
Auto; Manual |
| Numarul iluminatorului |
4 (lumina multi-core (IR + calda)) |
| Ajustare unghi |
Pan: -30° la 30°; Tilt: 0° la 80°; Rotatie: 0° la 360° |
| Tip lentile |
Focala fixa |
| Montura lentile |
M12 |
| Distanta focala |
2.8 mm |
| Deschidere maxima |
F1.6 |
| Camp de vizualizare |
2.8 mm: H: 101°; V: 54°; D: 120°; 3.6 mm: H: 83°; V: 43°; D: 100° |
| Control iris |
Fix |
| Distanta de focalizare apropiata |
2.8 mm: 1.1 m (3.61 ft); 3.6 mm: 1.7 m (5.58 ft) |
| Distanta DORI |
2.8 mm: Detectare: 63.6 m; Observare: 25.4 m; Recunoastere: 12.7 m; Identificare:6.4 m |
| IVS (Protectie perimetrala) |
Intrusion, tripwire (clasificare si detectie precisa a vehiculelor si persoanelor) |
| SMD |
SMD Plus |
| Cautare inteligenta |
Colaborare cu Smart NVR pentru cautare inteligenta rafinata, extragere si fuziune de evenimente |
| Compresie video |
H.265; H.264; H.264H; H.264B; MJPEG (doar substream) |
| Codec inteligent |
Smart H.265+; Smart H.264+ |
| Rata cadrelor video |
Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps); Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Capacitate fluxuri |
2 fluxuri |
| Rezolutie |
4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Control rata biti |
CBR/VBR |
| Rata biti video |
H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps |
| Zi/Noapte |
Auto(ICR)/Color/B/W |
| BLC |
Da |
| HLC |
Da |
| WDR |
120 dB |
| Balans de alb |
Auto; natural; lampa stradala; exterior; manual; personalizat regional |
| Control castig |
Auto/Manual |
| Reducerea zgomotului |
3D NR |
| Detectare miscare |
OFF/ON (4 zone, dreptunghiular) |
| Regiune de interes (RoI) |
Da (4 zone) |
| Iluminare inteligenta |
Da |
| Lumina dubla inteligenta |
Da |
| Rotire imagine |
0°/90°/180°/270° (Suport 90°/270° cu rezolutie 2688 × 1520 si mai mica) |
| Oglinda |
Da |
| Masca de confidentialitate |
4 zone |
| Microfon incorporat |
Da |
| Compresie audio |
G.711a; G.711Mu; G.726; PCM |
| Evenimente de alarma |
Fara card SD; card SD plin; eroare card SD; deconectare retea; conflict IP; acces ilegal; detectare miscare; modificare video; tripwire; intrusion; detectare audio; detectare tensiune; SMD; exceptie de securitate; alarma externa |
| Port de retea |
RJ-45 (10/100 Base-T) |
| SDK si API |
Da |
| Protocoale de retea |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P |
| Interoperabilitate |
ONVIF (Profile S & Profile G & Profile T); CGI |
| Utilizatori/Host |
6 (Latime de banda totala: 36 M) |
| Stocare |
FTP; SFTP; card Micro SD (suporta max. 256 GB) |
| Browser |
IE; Chrome; Firefox |
| Software de management |
Smart PSS Lite; DSS; DMSS; DoLynk Care |
| Client mobil |
iOS; Android |
| Securitate cibernetica |
Criptare video; Criptare firmware; Criptare configuratie; Digest; WSSE; Blocare cont; Jurnale de securitate; Filtrare IP/MAC; Generare si import certificat X.509; syslog; HTTPS; 802.1x; Boot sigur; Executie sigura; Upgrade sigur |
| Certificari |
CE-LVD: EN62368-1; CE-EMC: Directiva Compatibilitate Electromagnetica 2014/30/EU |
| Port audio |
Intrare: 1 canal (port RCA); Iesire: 1 canal (port RCA) |
| Intrare alarma |
1 canal: contact umed, 5 mA 3–5 VDC |
| Iesire alarma |
1 canal: contact umed, 300 mA 12 VDC |
| Alimentare |
12 VDC/PoE (802.3af) |
| Consum de putere |
Baza: 2.3 W (12 VDC), 2.8 W (PoE)
Max.: 7.1 W (12 VDC), 8.5 W (PoE) (H.265 + inteligenta activata + WDR + intensitate iluminator)
|
| Temperatura de functionare |
–40 °C pana la +60 °C (–40 °F pana la +140 °F) |
| Umiditate de functionare |
≤95% |
| Temperatura de stocare |
–40 °C pana la +60 °C (–40 °F pana la +140 °F) |
| Umiditate de stocare |
≤95% |
| Protectie |
IP67; IK10 |
| Material carcasa |
Metal |
| Dimensiuni produs |
55.0 mm × Φ108.9 mm (2.17" × Φ4.29") |
| Greutate neta |
0.41 kg (0.90 lb) |
| Greutate bruta |
0.55 kg (1.21 lb) |
