| Senzor de imagine |
Oxid de vanadiu neracit |
| Rezolutie |
256 × 192 |
| Pixel Pitch |
12 μm |
| Interval spectral |
8 μm to 14 μm |
| NETD |
< 40 mK (25°C, F1.0) |
| Lungime focala |
9.7 mm |
| IFOV |
1.24 mrad |
| Camp vizual (FOV) |
18.0° × 13.5° |
| Distanta minima de focalizare |
3.5 m |
| Apertura |
F1.0 |
| Zoom digital |
×2, ×4 |
| Senzor de imagine |
1/2.7" Progressive Scan CMOS |
| Rezolutie |
2688 × 1520 |
| Iluminare minima |
Culoare: 0.0176 Lux @ (F2.25, AGC ON), B/W: 0.0035 Lux @ (F2.25, AGC ON) |
| Viteza obturator |
1 s to 1/100,000 s |
| Lungime focala |
8 mm |
| Camp vizual (FOV) |
39.4° × 22.1° (in functie de model) |
| Apertura |
F1.6 |
| WDR |
120 dB |
| Colorare tinta |
Suportat in modurile white hot si black hot |
| Distanta IR |
Pana la 30 m |
| Intensitate si unghi IR |
Reglate automat |
| Distanta lumina alba |
Pana la 30 m |
| Alarma vizuala |
Lumina alba cu frecventa de clipire reglabila |
| Alarma audio |
2 tipuri de alarma auditiva (VCA si Exceptie de temperatura), 2 alerte vocale presetate, 6 alerte vocale definite de utilizator |
| VCA |
4 tipuri de reguli VCA (traversare linie, intruziune, intrare/iesire din regiune), pana la 8 reguli VCA |
| Masurarea temperaturii |
3 tipuri de reguli de masurare a temperaturii, pana la 21 reguli (10 puncte, 10 zone, 1 linie) |
| Gama de temperatura |
-20°C to 150°C (-4°F to 302°F) |
| Precizia masurarii temperaturii |
± 8°C (± 14.4°F) |
| Flux principal |
Termal: 25 fps (1280 × 720, 704 × 576, 640 × 512, 320 × 240) / Optic: 25/30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-flux |
Termal: 25 fps (704 × 576, 640 × 512, 320 × 240) / Optic: 25/30 fps (704 × 576, 352 × 288) |
| Compresie video |
H.265/H.264/MJPEG |
| Compresie audio |
G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM |
| Protocoale |
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour,SFTP,SRTP |
| Stocare retea |
MicroSD/SDHC/SDXC card (pana la 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| API |
ISAPI, HIKVISION SDK, si platforme de management terte, Open Network Video Interface (Profile S, Profile G) |
| Vizualizare simultana live |
Pana la 20 canale |
| Nivel utilizator/gazda |
Pana la 32 utilizatori, 3 nivele: Administrator, Operator, Utilizator |
| Securitate |
Autentificare utilizator (ID si Parola), legare adresa MAC, criptare HTTPS, IEEE 802.1x, control acces, filtrare adrese IP |
| Client |
iVMS-4200, Hik-Connect |
| Browser web |
Vizualizare live (plug-in permis): Internet Explorer 11 / Vizualizare live (fara plug-in): Chrome 57.0+, Firefox 52.0+ |
| Intrare alarma |
2, alarma intrare (0-5 VDC) |
| Iesire alarma |
2, alarma iesire (actiuni de raspuns configurabile) |
| Actiune alarma |
Inregistrare pe SD, iesire releu, captura inteligenta, incarcare FTP, legare e-mail |
| Intrare audio |
1, 3.5 mm Mic in/Line in interface Line input: 2 to 2.4 V [p-p], output impedance: 1 KΩ ± 10% |
| Iesire audio |
Nivel liniar, impedanta: 600 Ω |
| Interfata de comunicatie |
1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface (half duplex) |
| Limba client web |
32 limbi (inclusiv engleza, rusa, romana, franceza, germana, italiana, etc.) |
| Alimentare |
12 VDC ± 25%, φ 5.5 mm coaxial power plug PoE (802.3af, class 3) |
| Consum de energie |
12 VDC ± 25%: 0.5 A, Max. 6 W PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, Max. 6.5 W |
| Temperatura/Umeditate de operare |
Temperatura: -40°C to 65°C (-40°F to 149°F) Umiditate: 95% sau mai putin |
| Nivel de protectie |
IP67 Standard, protectie la fulgere TVS 6000V, protectie la supratensiune si protectie la tensiune tranzitorie |
| Dimensiuni |
321.3 mm × 106.1 mm × 107.0 mm (12.65" × 4.18" × 4.21") |
