| Senzor de imagine |
5 MP CMOS |
| Sistem de semnal |
PAL/NTSC |
| Rezolutie |
2560 (H) × 1944 (V) |
| Rata cadrelor |
TVI: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps; AHD: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps; CVI: 4 MP @ 30 fps, 4 MP @ 25 fps; CVBS: PAL/NTSC |
| Iluminare minima |
0.01 Lux @ (F1.2, AGC ON), 0 Lux cu IR |
| Timp de expunere |
PAL: 1/25 s pana la 1/50,000 s; NTSC: 1/30 s pana la 1/50,000 s |
| Lentila |
2.8 mm |
| Camp vizual |
2.8 mm, FOV orizontal: 85°, FOV vertical: 63°, FOV diagonal: 110° |
| Mod imagine |
STD/HIGH-SAT |
| AGC (Control automat al castigului) |
Da |
| Mod zi/noapte |
Auto/Color/BW (Alb-Negru) |
| Balans de alb |
Auto/Manual |
| Mod AE (Expunere Automata) |
DWDR, BLC, HLC, Global |
| Reducerea zgomotului |
2D DNR |
| Limba |
Engleza |
| Functie |
Luminozitate, Oglinda, Smart IR, Ascutime |
| Iesire video |
Comutabil TVI/AHD/CVI/CVBS |
| Intrare audio |
Microfon integrat |
| Conditii de operare |
-40°C pana la 60°C (-40°F pana la 140°F), Umiditate: 90% sau mai putin (fara condens) |
| Alimentare |
12 VDC ± 25% |
| Consum |
Max. 4.5 W |
| Nivel de protectie |
IP67 |
| Material |
Capac frontal: Metal, Corp principal: Plastic |
| Raza IR |
Pana la 40 m |
| Comunicare |
HIKVISION-C |
| Dimensiuni |
78.9 mm × 75.4 mm × 216.6 mm (3.10" × 2.97" × 8.53") |
| Greutate |
Aprox. 338 g (0.75 lb.) |
